Electronic Weighing Platform Scale

  • Range: 5kg~10t.
  • Size: Customizable.
  • Separation function: Separates items based on weight.
  • Basic configuration: Weighing platform, instruments, sensors, etc.
  • Automatic zeroing: Sets the scale to zero upon startup.
  • AC/DC power supply: Compatible with both AC and DC power sources.

Bincen Electronic Platform Scale is recognized for its accurate weighing and high precision, featuring a fast response for enhanced convenience. The intuitive display eliminates visual errors, and effective weighing software enables microcomputer management of data, ensuring scientific measurement.

With a range of 5 kg to 10 tons and customizable sizes, it also includes a separation function to categorize items by weight. The scale’s basic configuration features a weighing platform, instruments, and sensors, with automatic zeroing for startup accuracy. It is compatible with both AC and DC power sources, offering great versatility.

Function of Electronic Weighing Platform Scale

  • Automatic zeroing: Sets the scale to zero upon startup.
  • Manual peeling/zeroing: Allows for manual adjustment of the zero point.
  • AC/DC power supply: Compatible with both AC and DC power sources.
  • Digital display: Displays weighing data digitally.
  • Weight accumulation: Adds up multiple weights.
  • Counting function: Counts the number of items being weighed.
  • Weight inspection: Compares weight to a target value.
  • Separation function: Separates items based on weight.
  • Dynamic weighing: Measures weight while objects are in motion.
  • Data recording function: Records weighing data for later analysis.
  • Control alarm function: Triggers an alarm based on specific weight conditions.
Electronic Weighing Platform Scale 7

Specification of Electronic Weighing Platform Scale

  • Function: Zero setting, peeling, and accumulation;
  • Size: 400-2000mm × 400-2000mm weighing platform with various specifications, customizable;
  • Basic configuration: weighing platform, instruments, sensors, etc.
  • Range: 5kg~10t;
  • Accuracy: OIML Level III Accuracy: 1/5000, 1/6000, 1/7500, 1/10000; OIML Level II accuracy: 1/12000, 1/15000.
Electronic Weighing Platform Scale 6

Composition of Electronic Weighing Platform Scale

(1) Supporting high-precision instruments: XK3190-A12, XK3190-A23P, XK3190-A35E

  • High technology, high stability and reliability;
  • High measurement accuracy;
  • Unique anti-drift and creep compensation proprietary technology;
  • RS232 communication interface;
  • Customizable special function software.
XK3190-A12
XK3190-A12

It adopts high-precision analog-to-digital conversion technology and special software anti-vibration technology and applies to static weighing systems with 1~4 sensors such as electronic platform scales and electronic platform scales. High precision A/D conversion, readability up to 1/30000.

XK3190-A23P
XK3190-A23P

t is a three-window LCD pricing instrument with a built-in micro printer, which is suitable for static weighing systems using 1~4 sensors such as electronic platform scales, electronic platform scales, and electronic ground scales.

XK3190-A35E
XK3190-A35E

It is a platform scale instrument with a built-in label printer, and the printing format can be customized and edited. It adopts high-precision A/D conversion technology, which is suitable for high-precision multi-function weighing occasions.

(2) Types of high-precision sensors (domestic or foreign brands):

Types of high-precision sensors

Benefits of Choosing Bincen

  • Simplified Installation: Our products are designed for effortless installation, thanks to modular components and pre-integrated systems that eliminate the need for heavy machinery. This saves you time and money on installation costs and labor.
  • Comprehensive Support: We prioritize your satisfaction by offering a complete technical service system. This includes expert advice, clear installation instructions, and ongoing after-sales support. Even if on-site service isn’t available in your area, our detailed video guides and remote assistance ensure a smooth installation process.
  • Related Services: We offer relevant CE certification, customized solutions, ODM and OEM services, and a warranty that covers free replacement of damaged accessories.
  • Product Quality: Our weighing and batching controllers feature precise algorithms and consistent performance, ensuring accurate and reliable measurements.
  • Customer Focus: We are dedicated to providing exceptional customer service through our team of experienced engineers. They offer expert guidance throughout the sales process, including solution design, product selection, installation, debugging, and after-sales maintenance.

FAQ

A1: Yes, we can provide an operation video.

A2: It is 12 months.

A3: One-year warranty, discontinued online remote guidance service.

A4: At present, there are only repair points available in China. If you have repair needs, we will provide online remote guidance.

A5:

  1. Reach purchase intention after communication;
  2. Signing the contract;
  3. Pay deposit;
  4. Pay the balance after completion of production according to order;
  5. Delivery arrangements.
